Technical Specifications
General
| Output Range | 0-100 psig (0-7 bar), 0-15 psig (0-1.0 bar), 0-150 psig (0-10.3 bar), 0-2 psig (0-0.15 bar), 0-30 psig (0-2.1 bar), 0-60 psig (0-4 bar) |
|---|---|
| Exhaust Capacity | 4 scfm (120 NL/min) |
| Sensitivity | 1/8″ in. (3.2 mm) |
| Air Consumption | Less than 12.0 scfh (340 Nl/hr) |
| Mounting | Pipe, Panel, Bracket |
| Part Number | 429-829-020 |
| Check Valve | Yes |
| Brand | ControlAir |
| Manufacturer Part | 429-829-020 |
| Size | 1/4″ |
| Country of Origin | Made in the United States |
Materials & Construction
| Body Material | Diecast Aluminum Alloy |
|---|---|
| Other Material | Stainless steel, Brass, Plated Steel Acetal, Buna-N, Polyester, Phenolic Plastic |
Performance
| Flow Capacity | 80 scfm (2,264 Nl/min) |
|---|---|
| Max. Supply Pressure | 250 psig (17 bar) |
| Supply Pressure Sensitivity | Less than 0.1 psig for a 100 psig change (0.007 bar for a 6.7 bar change) |
| Ambient Temperature Limits | -40° to +160°F ‘(-40° to 71°C) |
Connections
| Port Size | 1/2″ BSP, 1/2″ NPT, 1/4″ BSP, 1/4″ NPT, 3/8″ BSP, 3/8″ NPT |
|---|
Dimensions & Weight
| Weight | 1.625 lbs (0.74 kg) |
|---|
