Technical Specifications
General
| Output Range |
0 – 15 psig (0 – 1.0 bar) |
| Exhaust Capacity |
4 scfm (120 NL/min) |
| Sensitivity |
1/8″ in. (3.2 mm) |
| Air Consumption |
Less than 12.0 scfh (340 Nl/hr) |
| Mounting |
Pipe, Panel, Bracket |
| Part Number |
429-829-048 |
| Non-Relieving |
Yes |
| Tamper Proof Cover |
Yes |
| Brand |
ControlAir |
| Manufacturer Part |
429-829-048 |
| Size |
1/4″ |
| Country of Origin |
Made in the United States |
Materials & Construction
| Body Material |
Diecast Aluminum Alloy |
| Other Material |
Stainless steel, Brass, Plated Steel Acetal, Buna-N, Polyester, Phenolic Plastic |
Performance
| Flow Capacity |
80 scfm (2,264 Nl/min) |
| Max. Supply Pressure |
250 psig (17 bar) |
| Supply Pressure Sensitivity |
Less than 0.1 psig for a 100 psig change (0.007 bar for a 6.7 bar change) |
| Ambient Temperature Limits |
-40° to +160°F ‘(-40° to 71°C) |
Connections
Dimensions & Weight
| Weight |
1.625 lbs (0.74 kg) |
