Technical Specifications
General
| Application | For mechanical interfaces to pneumatic actuators VDI / VDE 3845 |
|---|---|
| Hole spacing for mounting bracket | 80×30 mm / 130×30 mm |
| Suitable for shaft diameters | >38 |
| Brand | IFM |
| Manufacturer Part | IFM-Assembly Angle |
Materials & Construction
| Body Material | Stainless Steel, Adapter: Aluminum |
|---|
Dimensions & Weight
| Shaft height for valve drive | 30/40/50 mm |
|---|
