Technical Specifications
General
| Orifice | 1.2mm to 1.6mm |
|---|---|
| CV | 0.05 to 0.09 |
| Valve Type | 2 Way |
| Action | Direct Acting (Poppet) / Fast Response Time: <20msec |
| De Energized State | Normally Closed (NC) |
| Op Temp | Media with Viton Seal: 5°F to 248°F (-15°C to 120°C) / Media with PTFE Seal: -4°F to 356°F (-20°C to 180°C) |
| Coil Power | AC Coil: 33VA / DC Coil: 13-20W |
| Voltage Options | 12 VDC / 24 VDC / 24 VAC / 110/120 VAC (50/60Hz) / 220/240 VAC (50/60Hz |
| Voltage Tolerance | ±10% of Specified Voltage |
| Ingress Protection | IP65 |
| Insulation Class | F Class |
| Coil Duty | 100% ED (Continuous Duty) |
| Installation | No Orientation Requirement / Optimum Position: Flow Horizontal and Solenoid Vertical |
| Service | Liquid, Water, Oil, Air, Gas, Cryogens |
| Brand | STC Valve |
| Manufacturer Part | STC-2H012-016 |
Materials & Construction
| Body Material | Valve Body: 304 Stainless Steel / Seal: Viton (FKM), PTFE (Teflon) / Armature Assembly: Stainless Steel |
|---|
Performance
| Op Pressure | 0 PSI to 1000 PSI |
|---|
Connections
| Elec. Connection | DIN 43650, Form A |
|---|
