Technical Specifications
General
| Orifice | 5mm |
|---|---|
| Valve Type | 2 to Way |
| Action | Direct Acting |
| De Energized State | Normally Closed (NC) |
| Op Temp | 32°F to 122°F (0°C to 50°C) |
| Coil Power | 20W |
| Voltage Options | 12 VDC / 24 VDC / 24 VAC (50/60Hz) / 110/120 VAC (50/60Hz) / 220/240 VAC (50/60Hz) |
| Voltage Tolerance | ±10% of Specified Voltage |
| Ingress Protection | IP65 |
| Insulation Class | H Class |
| Coil Duty | 100% ED, Continuous Duty |
| Installation | No Orientation Requirement / Optimum Position: Flow Horizontal and Solenoid Vertical |
| Service | Liquid, Potable Water, Air |
| Brand | STC Valve |
| Manufacturer Part | STC-2P050 |
Materials & Construction
| Body Material | Valve Body: Delrin Plastic (Customizable to any plastic) / Armature Assembly: Stainless Steel |
|---|
Performance
| OP Pressure | Vacuum to 50 PSI |
|---|
Connections
| Elec. Connection | D: DIN 43650A / G: Grommet / M: Molded Cable / ATEX: Explosion Proof Coil (2W200C-ATEX) |
|---|
