Technical Specifications
General
| Output Ranges |
7 – 125 PSI |
| Max Supply |
150 PSI (9.9 kgf/cm^2) |
| Filter |
25 Micron Standard Sintered Brass Filter |
| Seals |
NBR |
| Brand |
STC Valve |
| Manufacturer Part |
STC-AW3000-5000 |
Materials & Construction
| Body Material |
Aluminum |
| Bowl Material |
Aluminum / Polycarbonate |
Performance
| Flow Capacity |
70 to 195 SCFM (2000 to 5500 LPM) |
| Temperature Limits |
40 – 140°F |
Connections
| Port Size |
1/4″ to 1″ NPT |
| Gauge Port Size |
1/4″ NPT / 1/8″ NPT |
Dimensions & Weight
Standards & Certifications
See Specification SheetDownload Specification Sheet (PDF)
